J&M 1012 - Upper Auger Linkage

29
Upper Auger Linkage
Description Part No.
1 1/4” Diameter Snap Ring JM0001870
2 Master Link w/ Keeper (11-1/8” x 3” x 3/4”) JM0035075
3 Main Fold Link (22-1/2” x 7-7/16” x 1”) JM0034658
4 1-1/4” ID x 1-1/2” OD x 2” Long Sleeve Composite Bearing JM0021957
5 5/8”-11 Gr5 Z Centerlock Hex Nut JM0002146
6 3/8”-16 Gr5 Z Centerlock Hex Nut JM0001512
7 1-1/4” Pin Keeper (4-5/8” Lg) JM0035930
8 3/8”-16 x 1-1/4” Gr5 Z Hex Bolt JM0016675
9 22” Hinge Pin w/ Keeper Weldment (23” Lg)(12 Series 20” Augers) JM0024966
10 5/8”-11 x 1-1/2” Gr5 Z Hex Bolt JM0002103
