Ladder Assembly
Description Part No.
1 1/2”-13 x 1-1/2” Gr5 Z Hex Bolt JM0002100
2 1/2” ID, 1-3/8” OD Z Flat Washer JM0003082
3 1/2”-13 Gr5 Z Centerlock Hex Nut JM0001511
4 3/8”-16 x 1” Gr5 Z SF Hex Bolt JM0002092
5 3/8”-16 Gr5 Z SF Hex Nut JM0002152
6 Side Swing Ladder Mount Bracket JM0012865
7 Swing Out Ladder Adjustable Tab JM0020977
8 12 and 22 Series Ladder JM0012858
9 Ladder Support Leg JM0012926
10 1/4”-20 x 1-1/4” Gr5 Z Hex Bolt JM0016673
11 Ladder Guide - 3/16” Thick JM0021947
12 1/4”-20 Gr5 Z Centerlock Hex Nut JM0001505
13 Inside Step - 12 series Ladder JM0035078
