42
Description Part No.
1 1”-14 Gr8 YZ Hex Nut JM0019926
2 1-1/4” x 8” x 14” Walker Frame Clamp Plate (114814CP) JM0010145
3 1”-14 x 7-1/2” Gr8 YZ Hex Bolt JM0019925
4 Walker Main Frame Weldment (Left)(FW-1L) JM0019922*
4 Walker Main Frame Weldment (Right)(FW-1R) JM0010082*
5 1-3/4” x 13-1/2” Bolt (1341312HB) JM0019981
6 1-3/4”-12 Z Gr5 Hex Jam Nut JM0009752
7 3-3/4” x 17-1/2” Pivot Pin (334PP) JM0019928
8 Walker - Triple Pivot Weldment - OAS (PBW-1R) JM0010170*
8 Walker - Triple Pivot Weldment - AS (PBW-1L) JM0025721*
9 3-3/4” ID, 4-1/2” OD Bronze Bushing (4” Lg) (BB-334) JM0010570
10 Walker Pivot Center Weldment (PCW-1) JM0010076*
11 3/4”-10 x 5-1/2” Gr5 Z Hex Bolt JM0015522
12 1”-14 x 3” Gr8 YZ Hex Bolt JM0019924
13 3/4”-10 Gr5 Z Centerlock Hex Nut JM0002147
Walking Tandem Dual Wheel Assembly
*-R = Red
*-B = Blue
*-G = Green
*-Y = Yellow
*-BLK = Black
When requesting an item with color, end the part number
with -R, -B, -G, -Y, or -BLK. (e.g. JM0000000-R)
