47
Spring Return Assembly
Description Part No.
1 1/4”-20 x 1.0” Gr5 Z Hex Bolt JM0002095
2 1-1/4” Idler Pulley (1/4” ID) JM0002439
3 Spring Return Housing for Grain Cart Roll Tarp JM0012974
4 1/4”-20 Gr5 Z Centerlock Hex Nut JM0001505
5 3/8”-16 Gr5 Z Centerlock Hex Nut JM0001512
6 3/4” x 2” Plastic Spacer JM0002444
7 3/8”-16 x 3” Gr5 Z Hex Bolt JM0001666
8 Spring Return Spring JM0000207
9 1/4”-20 x 1-1/2” Gr5 Z Hex Bolt JM0002447
10 1-5/8” Idler Pully (Long Spring Return) JM0012970
11 2” Black Plastic Spacer (1/4” ID x 1/2” OD) JM0002442
12 Rectangular Plastic Spacer for Spring Return JM0012973
13 Large Spring Return Pully Spacer (2 Holes) JM0018897
14 Aluminum Spacer for Spring Return (1-3/8” x 2-3/16”) Rectangular JM0002445
15 Spring Return Assembly (Grain Cart) JM0012965
16 Spring Return Cable (Grain Carts) JM0012981
