J&M 1012 - Page 33

33
Hydraulic Hoses & Cylinders
Description Part No.
1 1/4” x 236” Hydraulic Hose 236inch4M3k-4G-6MPX-4G-8MP JM0046664
2 3/8” Standard Coupling JM0019562
2 1/2” Standard Coupling JM0020407
3 1/4” x 43” Hydraulic Hose 43inch4M3k-4G-6MPX-4G-6MP JM0024904
4 1/2” x 43” Hydraulic Hose 43inch8M3k-8G-8MPX-8G-6MP JM0024906
5 2” x 36” Hydraulic Cylinder (JD236) JM0018523
5 Seal Kit for 2” x 36” Hydraulic Cylinder (JD472) JM0026544
6 1/4” x 304” Hydraulic Hose 304inch4M3k-4G-8MP-4G-6MP JM0046245
7 1/4” x 286” Hydraulic Hose 286inch4M3k-4G-8MP-4G-6MP JM0047274
8 1/4” x 21” Hydraulic Hose 21inch4M3k-4G-4MP-4G-6MPX JM0024896
9 3” x 24” x 1-1/2” Welded Cylinder (JD324) JM0019644
9 Seal Kit 3” x 24” Cylinder (JD324-1) (JD480) JM0037895
10 1-3/16” x 3-5/8” Clevis Pin (X-Tended Reach) JM0047300
11 3/8” Male NPT x 3/8” Female NPT; 90 Degree Elbow JM0030059
12 3/8” Male NPT x 3/8” Female NPT x 3/8” Female NPT; Street T JM0018266
13 Lock N Load Assembly JM0048754
14 1/4” x 478” Hydraulic Hose 478inch4M3k-4G-8MP-4G-4MP JM0046246
15 1-3/4” x 4” Hydraulic Cylinder (1/2” Clevis and Tab ends) JM0018564
15 Seal Kit for 1-3/4” x 4” Cylinder (SKHC-FCS) (JD459) JM0024892
16 1/4” Male NPT x 1/4” Female NPT; 90 Degree Elbow JM0020115
17 1/4” Male NPT-Swivel with .032 Orice (restrictor) JM0020113
18 1/2” Female NPT Pioneer (PQC-1) JM0018254
19 3/8” Male ORB x 3/8” Male NPT; 90 Degree Elbow JM0047350
20 1/2” Male ORB x 3/8” Female NPT; 90 Degree Elbow JM0047348
21 Solenoid Valve for Lock and Load (Black) JM0026256
22 Solenoid Coil for Lock and Load (Black) JM0026255
23 Check Valve for Lock and Load (Black) JM0026250
24 3/8” Male NPT x 3/8” Female NPT; 90 Degree Elbow JM0030059
25 1/2” Male NPT x 1/2” Female NPT; 90 Degree Elbow JM0047371
26 1/2” x 236” Hydraulic Hose 236inch8M3k-8G-8MP-8G-8MPX JM0047376
