Jandy CJ200 - Table of Contents

Page 3Cartridge Filters - CJ Series Filter
DATE OF INSTALLATION
INITIAL PRESSURE GAUGE READING (WITH CLEAN FILTER)
PUMP MODEL HORSEPOWER
FILTER MODEL SERIAL NUMBER
NOTES:
EQUIPMENT INFORMATION RECORD
TABLE OF CONTENTS
Section 1. Safety Information ........................... 4
1.1 Important Safety Warning ........... 4
1.2 General Safety Instructions ......... 4
Section 2. General Information......................... 5
2.1 Introduction ................................. 5
2.2 Description .................................. 5
2.3 General Requirements............. ... 5
Section 3. Installation Instructions.................... 6
3.1 Filter Location............................. 6
3.2 Filter Preparation......................... 6
3.3 Filter Installation ......................... 7
3.4 Locking Ring Installation............ 8
Section 4. Start-Up and Operation.................... 8
4.1 New Pool and Seasonal Start-up . 8
Section 5. Filter Disassembly and Assembly.... 9
5.1 Filter Element Removal .............. 9
5.2 Changing the Outlet Port............. 10
Section 6. Maintenance..................................... 11
6.1 General Maintenance................... 11
6.2 Pressure Gauge............................ 11
6.3 Cleaning the Filter Cartridge....... 11
Section 7. Winterizing....................................... 11
Section 8. Troubleshooting ............................... 12
Section 9. Parts List and Exploded View.......... 13
9.1 Jandy
®
Cartridge Filter, CJ Series 13
9.2 Jandy
®
CJ Cartridge Filter Exploded
View ........................................... 13
Section 10. Head Loss Curves........................... 14
10.1 Jandy
®
Cartridge Filter, CJ Series 14
