Section 10. Head Loss Curves
10.1 Jandy
®
Cartridge Filter, CS Series
0.00
0.50
1.00
1.50
2.00
2.50
3.00
3.50
4.00
0 30 60 90 120 150
FLOW RATE (GPM)
CS100
CS150
DESIGN
HEAD
LOSS
(PSI)
