Jandy JS Series User Manual

Page 17
JS Series Sidemount Sand Filters
Key
No. Description Part No.
1 Lid, Sand Filter R0487300
2 Lid Seal, Sand Filter R0487400
3 Gauge/Air Release Assembly R0357200
4 Pressure Gauge R0359600
5 Tank Adapter with O-Ring and Union R0552000
6 Diffuser, JS60-SM R0487501
7 Air Relief Assembly R0487600
8 Inlet Piping Kit JS60-SM R0519901
9 Outlet Piping Kit JS60-SM R0520001
10 Nuts, Slip Rings and Inner Spacers JS60 R0520100
11 Hub Assembly with 24" Laterals JS60 R0520200
12 Screw, #10 x 3/4" SS (Qty 6) R0488100
13 Sand Filter Drain Fitting Assembly R0488200
14 Drain Screen Assembly R0488300
15 Drain Fitting Seals Kit R0488400
16* O-Ring and Hardware Kit R0488500
17 Outlet Fitting, Complete JS60 R0520300
18 Inlet Fitting, Complete JS60 R0520400
19* Sweep Elbow SEFL 1002
* Not Shown
Section 10. Parts List and Exploded View
10.1 Jandy JS60-SM Sand Filter Parts List
Trademarks used herein are the property of their respective owners.
Key
No. Description Part No.
1 Lid, Sand Filter R0487300
2 Lid Seal, Sand Filter R0487400
3 Gauge/Air Release Assembly R0357200
4 Pressure Gauge R0359600
5 Tank Adapter with O-Ring and Union R0552000
6 Diffuser R0487500
7 Air Relief Assembly R0487600
8 Inlet Piping Kit JS100-SM R0487700
9 Outlet Piping Kit JS100-SM R0487800
10 Nuts, Slip Rings and Inner Spacers JS100 R0487900
11 Hub Assembly with 30" Laterals JS100 R0488000
12 Screw, #10 x 3/4" SS (Qty 6) R0488100
13 Sand Filter Drain Fitting Assembly R0488200
14 Drain Screen Assembly R0488300
15 Drain Fitting Seals Kit R0488400
16* O-Ring and Hardware Kit R0488500
17 Outlet Fitting, Complete JS100 R0488600
18 Inlet Fitting, Complete JS100 R0488700
19* Sweep Elbow SEFL 1002
* Not Shown
10.2 Jandy JS100-SM Sand Filter Parts List
