JS Series Sidemount Sand Filters
H0282300 RevG
Section 11. Head Loss Curves
11.1 Jandy JS Series Sand Filters
Design Head Loss Curves
Head Loss - JS Series Sand Filters
#20 Silica Sand
0
2
4
6
8
10
12
14
16
0 102030405060708090100110120
Flow Rate (gpm)
Design Head Loss
(ft head)
0.0
1.0
2.0
3.0
4.0
5.0
6.0
Design Pressure
Drop (psi)
JS60-SM
JS100-SM
