Page 18
Section 7. Product Specifications and Technical Data
7.1 Replacement Parts List
To order or purchase parts for Jandy
®
pumps, contact your nearest
Jandy
®
dealer. If they cannot supply you with what you need, contact
Jandy
®
customer service at 707.776.8200 or send an e-mail message to
info@jandy.com.
Key
No. Part No. Description Size (HP) Qty.
1 R0445101 Motor, single-speed SHPF .75 1
1 R0445102 Motor, single-speed SHPF 1.0 1
1 R0445103 Motor, single-speed SHPF 1.5 1
1 R0445104 Motor, single-speed SHPF 2.0 1
1 R0445105 Motor, single-speed SHPF 3.0 1
1 R0445101 Motor, single-speed SHPM 1.0 1
1 R0445102 Motor, single-speed SHPM 1.5 1
1 R0445103 Motor, single-speed SHPM 2.0 1
1 R0445104 Motor, single-speed SHPM 2.5 1
1 R0445106 Motor, 2-speed SHPM 2.0 1
1 R0445107 Motor, 2-speed SHPM 2.5 1
1 R0445101-07 Bolts
Washers
All 4
4
2 R0445200 Backplate, SHPF/SHPM
Mechanical Seal, Carbon
Mechanical Seal, Ceramic
O-ring
Bolts
Washers
All 1
1
1
1
8
8
3 R0445302 Impeller, SHPF .75 1
3 R0445303 Impeller, SHPF 1.0 1
3 R0445304 Impeller, SHPF 1.5 1
3
R0445305 Impeller, SHPF 2.0 1
3
R0445306 Impeller, SHPF 3.0 1
3
R0445302 Impeller, SHPM 1.0 1
3
R0445303 Impeller, SHPM 1.5 1
3
R0445304 Impeller, SHPM 2.0 1
3
R0445305 Impeller, SHPM 2.5 1
3
R0445304 Impeller, 2-speed SHPM 2.0 1
3
R0445305 Impeller, 2-speed SHPM 2.5 1
3 R0445302-06 Screw w/O-ring, Self-sealing All 1
4 R0445400 Diffuser
Screw
Washer
O-ring
All 1
2
2
1
5 R0445500 Mechanical Seal, Carbon
Mechanical Seal, Ceramic
All 1
1
6 R0445601 Body, Pump, SHPF/SHPM All 1
7 R0445700 Motor Mounting Foot Assembly, SHPF/SHPM
Screws
All 1
2
8 R0445800 Locking Ring
Lid
O-ring
All 1
1
1
9 R0445900 Filter Basket All 1
10 R0446000 Plug, Drain
O-ring
All 2
2
