Jandy SHPF User Manual

Page 19
Figure 10. SHPF and SHPM Exploded View
7.2 Exploded View
Key
No. Part No. Description Size (HP) Qty.
11 R0446101 Tail Piece (2" by 2½")
Coupling Nut
O-ring
.75-2.5 2
2
2
11 R0446102 Tail Piece (2½" by 3")
Coupling Nut
O-ring
3.0 2
2
2
12 R0446200 O-ring, Lid All 1
13 R0446300 O-ring, Backplate All 1
14 R0446400 O-ring, Tail Piece All 2
15 R0446500 Diffuser/Impeller Hardware
Screw w/O-ring, Self-sealing, Impeller Mounting
Screw, Diffuser Mounting
Washer, Diffuser Mounting
O-ring, Diffuser
All
1
2
2
1
16 R0446600 Backplate Hardware
Bolts
Washers
All
8
8
17 R0446700 Motor Hardware
Bolts
Washers
All
4
4
18 R0446800 Screws, Motor Mounting Foot 2
3
1
9
8
6
2, 5
11
7
2
10 (qty 2)
4
8, 12
2, 13
4, 15
14
3, 15
4 (qty 2),
15 (qty 2)
2 (qty 8),
16 (qty 8)
1 (qty 4),
17 (qty 4)
7 (qty 2),
18 (qty 2)
11
14
