Jandy Stealth SHPM User Manual

Section 7. Product Specications and Technical Data
7.1 Replacement Parts List
To order or purchase parts for Zodiac
®
pumps, contact your nearest Zodiac dealer. If they cannot supply you with what
you need, contact Zodiac technical support at 800.822.7933 or send an e-mail message to:
productsupport@zodiac.com.
Key No. Description Model No. (HP) Order Part No.
1 Single-speed Motor & Hardware, SHPF .50 R0445114
1 Single-speed Motor & Hardware, SHPF .75 R0445101
1 Single-speed Motor & Hardware, SHPF 1.0 R0445102
1 Single-speed Motor & Hardware, SHPF 1.5 R0445103
1 Single-speed Motor & Hardware, SHPF 2.0 R0445104
1 Single-speed Motor & Hardware, SHPF 3.0 R0445105
1 Single-speed Motor & Hardware, SHPF 5.0 R0490200
1 Single-speed Motor & Hardware, SHPM .75 R0479301
1 Single-speed Motor & Hardware, SHPM 1.0 R0479302
1 Single-speed Motor & Hardware, SHPM 1.5 R0479303
1 Single-speed Motor & Hardware, SHPM 2.0 R0479304
1 Single-speed Motor & Hardware, SHPM 2.5 R0479305
1 Two-speed Motor & Hardware, SHPM 1.5 R0479307
1 Two-speed Motor & Hardware, SHPM 2.0 R0479308
1 Two-speed Motor & Hardware, SHPM 2.5 R0479309
1 Single-speed Motor & Hardware, SHPF, 3 Phase 1.0 R0479101
1 Single-speed Motor & Hardware, SHPF, 3 Phase 1.5 R0479102
1 Single-speed Motor & Hardware, SHPF, 3 Phase 2.0 R0479103
1 Single-speed Motor & Hardware, SHPF, 3 Phase 3.0 R0479104
1 Two-speed Motor & Hardware, SHPF 1.0 R0445113
1 Two-speed Motor & Hardware, SHPF 1.5 R0445106
1 Two-speed Motor & Hardware, SHPF 2.0 R0445107
2 BackplateKitw/Hardware,O-ring&MechSeals,SHPF/SHPM .50-3.0 R0445200
2 BackplateKitw/Hardware,O-ring&MechSeals,SHPF 5.0 R0445201
3 ImpellerReplacementKit,SHPF .50 R0807204
3 ImpellerReplacementKit,SHPF .75 R0807203
3 ImpellerReplacementKit,SHPF 1.0, 1.0-2 R0807202
3 ImpellerReplacementKit,SHPF 1.5, 1.5-2 R0807201
3 ImpellerReplacementKit,SHPF 2.0, 2.0-2 R0807200
3 ImpellerReplacementKit,SHPF 3.0 R0807205
3 ImpellerReplacementKit,SHPF 5.0 R0807207
Symptom Possible Problem/Solution
There is no debris blocking
the impeller and the pressure
is still low.
Thepumpimpelleranddiffuserareshowingsignsofnormalwear.Haveaqualified
service technician check the impeller and diffuser and replace as necessary.
If the pump is part of a relatively new installation, it could be an electrical problem.
Contactaqualifiedservicetechnician.Havethetechniciancheckforlooseelectrical
connections and check the voltage at the pump motor while it is in operation. The
voltage must be within 10% of the motor's data plate rating. If the voltage is not
within10%,contactaqualifiedelectricianand/orthelocalpowerserviceprovider.
The pump is leaking water
between the motor and pump
body.
This is caused by a damaged or failed mechanical seal. Pump seal is leaking air.
Haveaqualifiedservicetechnicianreplacetheseal.
The pump gets hot and shuts
off periodically.
Ensurethatthereisadequateroomaroundthemotortocirculateairandkeepthe
motorcool.Haveaqualifiedelectriciancheckforlooseconnectionsandcheckthe
voltage at the pump motor while it is in operation. The voltage must be within 10%
ofthemotor'sdataplaterating.Ifthevoltageisnotwithin10%,contactaqualified
electrician and/or the local power service provider.
