ENGLISH
Jandy
®
TruDose
TM
Chemical Controller
|
Installation & Operation Manual
Section 2. Getting Started
This manual provides installation and basic operation
instructions for the TruDose
Chemical Controller.
Read the installation and operation instructions
completely before proceeding with the installation.
Keep this manual in a safe place for future reference.
2.1 System Components
2.1.1 TruDose Chemical Controller
The TruDose Chemical Controller allows automatic
monitoring and adjusting of pH and ORP (adjusting
requires an optional saltwater chlorinator connected)
levels through a simple, user-friendly interface, resulting
in easier management of water balance in swimming
pools.
It can be easily installed into your existing pool
environment and equipment and monitors and displays
the pH and ORP levels using LEDs and digital readouts
on the front panel of the unit. In addition, four separate
function buttons allow simple pushbutton control of
these individual parameters:
• Mode - Auto (running), pH settings, ORP settings.
• Set level - pH or ORP level to be maintained.
• Dose Time - Dose time (seconds) for pH.
Overfeed time (hours) for ORP.
• pH Cal - pH calibration for variation in pH sensors
The controller has a peristaltic pump that feeds liquid
acid. The acid pump will turn on if the pH measured is
higher than the setpoint dened by the user.
When the ORP measured by the ORP sensor is lower
than the setpoint dened by the user, the controller
turns on the chlorination from the optional saltwater
chlorinator to produce chlorine and reach the desired
ORP. When the ORP reaches the setpoint, the chemical
controller has the ability to turn o the chlorination from
the saltwater chlorinator. The saltwater chlorinator is not
provided with the TruDose chemical controller.
2.1.2 Flow Cell with Flow Switch
The ow cell houses a ow switch and holds the pH
and ORP sensors. These sensors connect to the chemical
controller to monitor the pH and ORP levels in the water.
The ow switch veries that water is owing during
a feed cycle and sends the controller instructions to
deactivate the feed if water is not owing. Operation of
this controller without a functioning ow switch may
result in under-dosing or over-dosing of chemicals.
2.1.3 Other Components
• pH sensor - standard (use only part number
R0894300)
• ORP Gold Sensor - standard (use only part number
R0894400)
• Fittings - for tapping installation of ow cell input/
output
• In-line Filter - install prior to the ow cell to protect
the ow switch and the pH and ORP sensors.
• Tubing - 25 feet of 3/8" and 20 feet of 1/4" for
providing acid to and from the acid tank.
• pH Pump - including tubing and ttings - integrated
peristaltic pump for pH-controlling acid.
• Mounting Board - ABS plastic with mounting holes
and stainless hardware (18" x 10").
• 1/4" NPT tap (included)
NOTE: Using undiluted acid could lead to corrosion
or overfeeding issues. Use muriatic acid only
(not provided). Dilute the acid 4:1 following
the safety recommendations of the chemical
manufacturer, and use personal protective
equipment. For example: For a 5 gallon tank,
there would be 4 gallons of water and 1 gallon
of muriatic acid.
TruDose R-kits
1 R0894300 PH SENSOR
2 R0894400 ORP SENSOR
3 R0944100 PCBA REPLACEMENT
4 R0944300 POWER CABLE
5 R0944400 CONTROLLER ONLY
6 R0944500 1/4" BLACK POLY TUBING
(25 FOOT ROLL)
7 R0944600 3/8" BLACK POLY TUBING
(28 FOOT ROLL)
8 R0944900 FLOW CELL W/ FLOW SWITCH,
VLV, FTGS 10
9 R0945000 INLINE FILTER W/SCREEN &
FTGS
10 R0945100 FLOW SWITCH
11 R0945200 SQUEEZE TUBES (2 PACK)
12 R0945300 PUMP ACCESSORY KIT
13 R0945400 PERISTALTIC ACID PUMP
14 R0961700 PUMP ROLLER ASSEMBLY
15 R0962100 TRUDOSE SWC CABLE 24 VDC
