Measuring process
The UMG 96RM-PN measures continuously and
calculates all effective values over a 10/12 period
interval. The device measures the real effective value
(TRMS) of the voltages and currents connected to
the measurement inputs.
Operating concept
You can program and call up the measured values via
many routes using the UMG 96RM-PN.
• Directly on the device via 2 buttons.
• Using the GridVis programming software.
• Using the device homepage (no programming).
• Using the Modbus protocol.
You can modify and call up the data using
the Modbus address list. The list can be called up
via the device's home page and can be found on
the enclosed CD.
• Using the PLC within a PROFINET environment.
This operation manual only describes how to operate
the UMG 96RM-PN using the two buttons.
The GridVis programming software has its own "online
help" system.
GridVis network analysis software
The UMG 96RM-PN can be programmed and read out
using the GridVis network analysis software (Download:
www.janitza.com). For this, a PC must be connected to
the UMG 96RM-PN via a serial interface (RS485) or by
ethernet.
GridVis features
• Programming the UMG 96RM-PN
• Graphical representation of measured values
