janitza UMG 96 RM-PN User Manual

7
UMG 96RM-PN
Number Part no. Designation
2 52.22.251 Mounting clips
1 10.01.855 Screw-type terminal, pluggable, 2-pole (auxiliary power)
1 10.01.849 Screw-type terminal, pluggable, 4-pole (voltage measurement)
1 10.01.871 Screw-type terminal, pluggable, 6-pole (current measurement I1-I3)
1 10.01.875 Screw-type terminal, pluggable, 2-pole (current measurement I4)
1 10.01.865 Screw-type terminal, pluggable, 10-pole (digital/analogue inputs/outputs)
1 10.01.857 Screw-type terminal, pluggable, 2-pole (RS 485)
1 10.01.859 Screw-type terminal, pluggable, 3-pole (digital/pulse output)
1 08.01.505 Patch cable 2 m, twisted, grey (connection UMG 96RM-PC/switch)
1 52.00.008 RS485 termination resistor, 120 ohms
1 29.01.065 Silicone seal, 96 x 96
1 15.06.015 Interface converter RS485 <-> RS232
1 15.06.025 Interface converter RS485 <-> USB
Available accessories
