Table 1 - Parameter list
0 SHORT RD/WR - Device address 0 - 255
(*1)
1
1 SHORT RD/WR kbps Baud rate (0=9.6kbps, 1=19.2kbps, 0 - 7 4
2=38.4kbps, 3= 57.6kbps (5 - 7 for internal
4=115.2kbps) use only)
3 SHORT RD/WR - Stoppbits 0..3 0
0 = 1 Bit, none parity
1 = 2 Bits, none parity
2 = 1 Bit, even parity
3 = 1 Bit, uneven parity
10 FLOAT RD/WR A Current transformer I1, primary 0 - 1,000,000
(*2)
5
12 FLOAT RD/WR A Current transformer I1, sec. 1 - 5 5
14 FLOAT RD/WR V Voltage transformer V1, prim. 0 - 1,000,000
(*2)
400
16 FLOAT RD/WR V Voltage transformer V1, sec. 100, 400 400
18 FLOAT RD/WR A Current transformer I2, primary 0 - 1,000,000
(*2)
5
20 FLOAT RD/WR A Current transformer I2, sec. 1 - 5 5
Address Format RD/WR Unit Comment Setting range Default
Parameters and Modbus address list
The excerpt of the following parameter list contains settings
necessary for proper operation of the UMG 96RM-PN,
e.g. current transformers and device address. The values
in the parameter list can be described and read.
The excerpt of the measured value list stores
the measured and calculated measured values, status
data for the outputs, and logged values for viewing.
C
A complete overview of the parameters and
measured values as well as explanations
on selected measured values can be found
in the document "Modbus Address List",
which can be found on the CD or online.
C
The addresses listed in this documentation
within the range 0-800 can be set directly
on the device. The addresses in the range
of 1000 and above can only be edited via
Modbus!
(*1)
The values 0 and 248 to 255 are reserved and must not be used.
(*2)
The adjustable value 0 does not produce any meaningful work values, and must not be used.
