10
UMG 96RM-P/-CBM
Measuring process
The UMG 96RM measures continuously and calculates all
effective values over a 9 period interval. The UMG 96RM
measures the real effective value (TRMS) of the voltage
and current connected to the measurement inputs.
Parameterising
You can parameterise the UMG via buttons 1 and 2 or
via the RS485 or USB interface.
You can only parameterise a small portion of the functions
directly on the device via the buttons. The list of functions
can be found in table 1 of the installation instructions for
the basic device.
All functions can be parameterised via the serial
interfaces and with the GridVis programming software.
Only the RS485 interface is available on
the basic device.
C
Additional components that are not
included in the scope of deliverables will
be required for parameterisation via the
RS485 interface.
C
