● Threading the Upper Looper
Place a spool of thread on the spool pin second
from the right.
* The points to thread for upper looper are marked
in red.
* A convenient threading chart is placed on the
machine body inside the looper cover.
[1]Draw the thread through the thread guide second
from the right from back to front.
1
Thread guide
[2]Pass the thread through the holes in the second
row from the right of thread guide plate as
illustrated.
2
Thread guide plate
[3]Pass the thread through the left side of looper
thread guide sliding the thread from right to left.
3 Looper thread guide
1
2
3
4
5
6
9
1
2
3
[1]
[2]
[3]
* If the thread is coming out from the thread guide
groove, pass the thread through the thread guide
hole again as shown.
8
7
To Next Page
