38
Replacing the Light Bulb
[1]
Turn off the power switch and unplug the
machine.
[2]Loosen the face plate set screw, and remove the
face plate.
1
Face plate
2 Set screw
To remove:
Push and twist to the left.
To attach:
Push and twist to the right.
Reattach the face plate, and retighten the face plate
set screw.
3
Light bulb
4 To remove
5 To attach
Note:
* The machine is designed to use a 15 WATT
maximum light bulb.
* The light bulb will be HOT. Protect your fingers
when you handle it.
Cleaning the Feed Dog
[1]Turn off the power switch and unplug the
machine.
[2]Open the looper cover and side cover.
[3]Remove the needles and presser foot.
[4]Remove the needle plate set screw, and remove
the needle plate.
1
Needle plate
2 Needle plate set screw
[5]Brush out the lint around the feed dogs to the
front by using the lint brush or use a vacuum
cleaner.
[6]Reattach the needle plate, presser foot and
needles.
Close the looper cover and side cover.
1
Feed dog
[1, 2, 3, 4]
[5, 6]
1
2
3
4
5
2
1
1
