[1]Pull the thread guide bar up as far as it will go.
[2]Turn the thread guide bar so that the thread
guides are right above the spool pins.
The Position of Thread Guide Bar
1 Thread guide bar
2 Thread guide
3 Stoppers
4 Spool pin
Attaching the Spool Holder Cap and Net
[1]When you use a small thread spool, pull out the
spool holder from the spool pin. Then place the
spool with its slit side up, and put the spool
holder cap on top of it.
[2]If the thread slips down from the spool
during threading and/or sewing, put a net on the
spool as illustrated to prevent jamming.
* The spool holder cap and net are optional
accessories.
1
Net
2 Spool pin
1 Spool holder
2 Spool pin
3 Spool holder cap
4 Slit
1
2
3
4
1
3
4
2
1
2
[1]
[2]
[1]
[2]
