21
[3]Insert the thread between tension discs from the
right. Then pull both sides of thread.
3 Right needle thread tension dial
[4]Turn the handwheel toward you to bring the
needle bar to its highest position, then pass the
thread through the right needle thread guide and
the thread take-up lever cover.
4
Right needle thread guide
5 Thread take-up lever cover
[5]Pass the thread through the needle thread guide
sliding the thread from left to right.
[6]Pass it through the needle bar thread guide from
left to right.
[7]Thread the right needle from front to back and
pull the thread about 10 cm (4”) from the eye of
the needle to the back.
6
Needle thread guide
7 Needle bar thread guide
8 Right needle
[3]
[4]
[5, 6, 7]
3
5
4
6
7
8
