23
[3]Insert the thread between tension discs from the
right. Then pull both sides of thread.
[4]Turn the handwheel toward you to bring the
needle bar to its highest position, then pass the
thread through the thread take-up lever cover.
3
Left needIe thread tension dial
4 Thread take-up lever cover
[5 Pass the thread through the needle thread guide
sliding the thread from right to left.
[6]Pass it through the needle bar thread guide from
left to right.
[7]Thread the left needle from front to back and pull
the thread about 10 cm (4”) from the eye of the
needle to the back.
5
Needle thread guide
6 Needle bar thread guide
7 Left needle
- Gently pull all four thread ends towards the
back of the machine.
- Run threads under the presser foot and lower
the presser foot.
- Close side cover and looper cover.
- Turn handwheel toward you to chain off three
or four stitches.
The sewing preparation is now complete.
[3, 4]
[5, 6, 7]
3
4
5
6
7
