Janome MC350E - Page 45

PARTSLIST
15
MC 350E
1 852631001
852631104
2 852016705
3 852610004
4 852017005
5 852611005
6 850612103
7 852505005
8 852633003
9 852019018
10 852020104
11 852519002
12 000120203
13 852059009
14 825183010
15 000096508
16 000115607
17 000066705
18 832177002
19 852023004
20 850524004
21 852058101
22 852518001
23 852053003
24 860557007
Front cover (whole unit)(JAI,JCA)
Front cover (whole unit)(JNBV,JA,JUK,JLA)
Front cover
LCD (unit)
LCD set plate (upper)
LCD set plate (lower) (unit)
Inverter (unit)
LCD harness (unit)
Printed circuit board A (unit)
Card guide
Start/stop button
Printed circuit board F (unit)
Setscrew 3x8(B)
Emblem
Arm thread guide (lower)
Setscrew 3.5x25
Setscrew TP 4x8
Setscrew 3x8
Washer
Front cover cap
Inverter harness (unit)
Button 1
Printed circuit board F2 (unit)
Start/stop button support spring
Ferrite core (JNBV,JA,JUK,JLA)
NO. Parts # Description
