Jay electronique UD Series User Manual

UD - 319472K - 63 -FRENDE
Radio channel
number
(see list in
appendix)
Type of function
buttons (2) on first
row (starting from
bottom of
transmitter)
Type of function
buttons (2) on
second row
Type of function
buttons (2) on
third row
UDE
-
10+2 button version :
Type of function buttons(2) on fifth row
or
6+2 and 8+2 button versions :
0 (zero)
Radio bands and version :
0
= Radio 433-434MHz
1
= Radio 433-434MHz + "starting up with IR validation" option
2
= Radio 433-434MHz without electronic key (1)
3
= Radio 433-434MHz + "starting up with IR validation" option and without electronic key (1)
A
= Radio 869MHz
B
= Radio 869Mhz + "starting up with IR validation" option
C
= Radio 869Mhz without electronic key (1)
D
= Radio 869MHz + "starting up with IR validation" option and without electronic key (1)
E
= Radio 911-918Mhz
F
= Radio 911-918MHz + "starting up with IR validation" option
Additional function (3) :
1
= standard, without additional function
3
= "coupled travelling cranes" option "tandem lift" type
4
= "micro-speed" option
5
= "travelling crane transfer" option "pitch and catch" type
6
= "Transmitter-Receiver association at start-up" option
x
= special (equipment definition covered by a
customization data sheet)
8+2 and 10+2 button versions :
Type of function buttons(2) on fourth row
or
6+2 button version :
0 (zero)
1 = BPSV, BPSV
2 = BPDV, BPDV
3 = BPSV, COM2
4 = BPSV, COM3
5 = COM2, COM2
6 = COM2, COM3
7 = COM3, COM3
8 = BPSV, COM3R
9 = COM2, COM3R
A = COM3, COM3R
B = COM3R, COM3R
C = Cover, cover
D = BPSV, BPTR
E = COM2, BPTR
R
2
1
R
2
1
R
2
1
R
2
1
R
2
1
R
2
1
R
2
1
R
1
R
1
.
1
2
R
.
1
R
.
1
R
.
1
R
(2)= Types of function buttons per row :
1
1
1,2
1,2
1
1
1
1
1
2
3
1
1
2
3
1
.
1
R
.
1
2
R
.
1
2
R
2.3.1- Transmitter UDE
Example : UDE013600-011
- 433-434MHz radio transmitter UDE, 6+2 button version, without «IR start-up validation» option,
with an electronic key, buttons configuration : first row BPSV-BPSV, second row BPSV-COM2, third
row COM2-COM3, label kits ref:UWE202 and UWE207 are supplied with transmitter and the pre-
programmed radio channel is 01 (433.1 MHz).
2.3- Product identification
(according to sales reference)



See §5 «Technical data» for button description
See §3.5 concerning programming restrictions due to the use of switches on
row 1 and row 2.



(1) = Only for auxiliary transmitter.
(3) = A technical manual is supplied for certain additional options
