Jay electronique UD Series User Manual

- 64 - UD - 319472KFR EN DE
Number of outputs :
A
= 6 function relays (1 relay board installed)
B
= 12 function relays (2 relay boards installed)
C
= 18 function relays (3 relays boards installed)
(the receiver
UDR
is systematically equipped with :
2 safety relays + 1 "Horn" relay)
UDR
-
0
Programming of button - relay correspondence :
Number of relays controlled by BPDV (double speed
pushbutton)
1
= 3 relays or no BPDV on transmitter
2
= 4 relays
x
= special (equipment definition covered by a customization
data sheet)
Programming of transmitter BPSV and
BPDV button interlocking :
0
= no interlocking or COM (switch) on each row
1
= interlocking button n°1-n°2, n°-n°4, n°5-n°6
with output relays set to OFF
2
= interlocking button n°1-n°2, n°-n°4, n°5-n°6
with priority on left button
3
= interlocking button n°1-n°2, n°-n°4, n°5-n°6
with priority on right button
x
= special (equipment definition covered by a
customization data sheet)
Programming button - relay correspondence :
Type of control for COM3,COM3R and BPTR (switches
with 3 positions) on transmitter
1
= Type : 1/1+2/2
or
no COM3/3R/BPTR on transmitter
2
= Type : 1/OFF/2
3
= Type : 1/2/1+2
x
= special (equipment definition covered by a
customization data sheet)
Power supply :
4
= 12 - 24 VDC
A
= 24 - 48 VAC
B
= 115 - 230 VAC
Radio bands and version :
0
= Radio 433-434MHz
1
= Radio 433-434MHz + "starting up with IR validation" option (2)
A
= Radio 869MHz
B
= Radio 869MHz + "starting up with IR validation" option (2)
E
= Radio 911-918MHz
F
= Radio 911-918MHz + "starting up with IR validation" option (2)
Additional option (1) :
0
= standard
2
= "Horn n°2"
3
= "coupled travelling cranes"
4
= "Micro-speed"
5
= "travelling crane transfer"
6
= "Transmitter-Receiver association at start-up"
UDF
Kit version :
1
= 1 infrared module
2
= 2 infrared modules
2.3.2- Receiver UDR
Example : UDR0BB00-112
- UDR radio receiver 433-434MHz,without IR start-up validation, 3+12 relays, power supply:
115-230VAC, without programmed interlocking, without BPDV on transmitter, COM3/COM3R
or BPTR of the transmitter are : 1/OFF/2.
2.3.3- Infrared module UDF
(for «starting up by infrared validation» option)
The number of module to be ordered is in function of the equipment starting up area, up to 3
UDF modules can be connected to UDR receiver.
Each UDF module is delivered with 1 M16 plastic cable gland, a 10m extension cable and a
mounting bracket.
(1) = A technical manual is supplied for certain additional options
(2) = This only includes the required programming for the receiver.
The UDF IR modules must be ordered separately.
