- 78 - UD - 319472KFR EN DE
NB : if this procedure is not observed the transmitter indicates an error with the red and green
indicator light :
- «3 flashes error type» (The green and red leds flash 3 times, mark a break, then flash 3
times etc.) : resume identity code copy procedure described in § 3.5.4.
- «5 flashes error type» (The green and red leds flash 5 times, mark a break, then flash 5
times etc.) : Stop or startup error (make sure that the pack battery is correctly inserted in the
transmitter housing and resume the radio remote control startup procedure).
3.3- First radio remote control startup
1- Switch ON the UDR receiver.
2- Plug the UDB2 battery pack into UDE transmitter housing..
3- Install the electronic key on the transmitter.
4- Copy electronic key identity code to UDE transmitter memory, see procedure on § 3.5.4.
5- Unlock the transmitter stop palmswitch button.
6- Press the green «On/Horn» button until the receiver is started up. (safety relays are activated).
If the remote control is equipped with the option " start up by infrared validation " : with
the transmitter, aim at the infrared UDF module bounding the zone of starting up while pressing
on the green "On / Horn" button.
See startup block diagram on next page
To stop the radio remote control : press the UDE transmitter stop palmswitch button.
