JBL CBT1000 - Bracket Parts Dimensional Diagrams

BRACKET PARTS DIMENSIONAL DIAGRAMS
50
[2.0]
48
[1.9]
196
[7.7]
M6 Bolt
Clearance
Holes
50
[2.0]
29
[1.1]
184
[7.3]
104
[4.1]
24
[1.0]
209
[8.2]
Narrow
Pole-Strap
Slots
Wide
Pole-Strap
Slots
Center Recessed
Channel for
Improved
Pole-Mount
Stability
WALL BRACKET TOP/BOTTOM SECTIONS
Dims in mm [in]
21
