APPENDIX A - MTC-CBT-OS2 Offset Bracket
MTC-CBT-OS3 Offset Bracket must be used when the CBT 1000E (extender) is located on the top
versus on the bottom of the CBT 1000 (full-range speaker).
The optional MTC-CBT-OS3 bracket is part of the CBT1K-ACC1 kit.
MTC-
CBT-OS3
BRACKET
Hardware Included with MTC-CBT-OS3:
M8 x 20 mm
PAN HEAD
BOLTS
M6
FLAT WASHERS
M6 SPLIT
LOCK WASHERS
Tool Required:
#2 Phillips Head
Screwdriver
