JBL CBT1000 - CBT1000 Down-Tilt with Swivel Bracket

Option 3c) CBT1000 Mounting with Down-Tilt Capability and SWIVEL BRACKET
(for Horizontal Swivel/Pan aiming capability)
M6 Hex Wrench
M6 x 20 mm
SOCKET HEAD BOLT
M6 SPLIT
LOCK WASHERS
M6 FLAT WASHERS
M8
FLAT WASHER
M8 SPLIT
LOCK WASHER
M8 x 20 mm
PAN HEAD
BOLT
8 PLACES:
8 PLACES:
Down-tilt range 0° to -15°
6
