Contents
Important Safety Instructions .............................................................................. 2
JBL DECLARATION OF CONFORMITY .............................................................. 4
1.0 Welcome ....................................................................................................... 5
1.1 Features .................................................................................................. 5
1.2 How to Use this Manual ......................................................................... 5
2.0 Setup ............................................................................................................ 6
2.1 Unpacking Your Amplifier . ..................................................................... 6
2.2 Installing Your Amplifier .......................................................................... 6
2.3 Ensuring Proper Cooling ........................................................................ 9
2.4 Choosing Input Wire and Connectors .....................................................9
2.5 Choosing Output Wire and Connectors ................................................10
2.6 Wiring Your Audio System .....................................................................11
2.7 Connect to AC Mains ............................................................................12
2.8 Protect Your Speakers ...........................................................................12
2.9 Startup Procedure .................................................................................12
3.0 Operation .................................................................................................... 13
3.1 Precautions ........................................................................................... 13
3.2 Front Panel Controls and Indicators ......................................................14
3.3 Rear Panel Controls and Connectors .................................................... 14
Appendix A: Optional Item - Transformer module............................................. 15
Appendix B: Specifications ............................................................................... 17
Appendix C: AC Power Draw and Thermal Dissipation..................................... 17
Appendix D: Contact Information ...................................................................... 18

Other manuals for JBL CSA-2120

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the JBL CSA-2120 and is the answer not in the manual?

JBL CSA-2120 Specifications

General IconGeneral
Output Power (two channels at 1 kHz power, THD+N<0.5%):4 Ohms 120 W 8 Ohms 120 W
Frequency Response (1 watt into 4 or 8 Ohms):+1/-1 dB
Load Impedance:Rated for 4 or 8 Ohms
Sensitivity (8 Ohms load):1.4 Vrms
Signal to Noise Ratio (below rated 8-Ohm power at 1 kHz, A weighted):>100 dB
Crosstalk (Rated into 8 Ohms):70 dB below rated from 20 Hz to 1 kHz; 50 dB below rated at 20 kHz
Input Impedance (nominal):Balanced: 20 k Ohms Unbalanced: 10 k Ohms
Maximum Input Signal:+20 dBu typical
AC Line Voltage and Frequency Confgi urations Available:100-240 V, 50/60 Hz
Auto-Standby:Go into auto-standby: 1 hour Recovery time: < 1 ms Recovery threshold: -60dBu
Operating Temperature:0° C to 40° C at 95% relative humidity (non-condensing)
Weight and Dimensions IconWeight and Dimensions
Dimensions (W x H x D) :8.2” x 1.7 x 7” (209 mm x 44 mm x 178 mm)
Net Weight:1 kg (2.1 lbs)
Shipping Weight:1.5 kg (3.4 lbs)
