SUB300 Amplifier
Not For Sale
SUB300 Cabinet
Not For Sale
10" Woofer DCR=3.4Ω
25MF12DZB-DW01
Rubber Foot Base (4)
321-ABS-00009
Foot Screw (4)
352-HM04030D500
Main Body Plastic Foot (4)
321-ABS-00008
Port Tube
249-ABS-00175
Woofer & Amplifier Screw (15)
352-AM04020D210
SUB300
Exploded View
SUB300 (SCS300.7sys)
9
