SUB300 120v Electrical parts List
Part Number Description Qty Reference Designator
Input/Main PCBs
Resistors
110-14103j26 resistor 10K 1/4W ± 5% CF 26mm 3 R503,504,10
110-14222j26 resistor 2.2K 1/4W ± 5% CF 26mm 1
R511
110-14432j26 resistor 4.3K 1/4W ± 5% CF 26mm 1 R506
110-14472j26 resistor 4.7K 1/4W ± 5% CF 26mm 1 R505
110-16102j26
resistor 1K 1/6W ± 5% CF 26mm
5 R153,213,214,215,254
110-16103j26 resistor 10K 1/6W ± 5% CF 26mm 28
R128,13,0149,150,209,212,216,217,220,221,222,225,226,
227,228,229,230,232,240,248,260,305,306,308,311,314,
319,325
110-16104j26
resistor 100K 1/6W ± 5% CF 26mm
6 R122,126,231,263,266,307
110-16105j26
resistor 1M 1/6W ± 5% CF 26mm
1 R259
110-16122j26
resistor 1.2K 1/6W ± 5% CF 26mm
1 R265
110-16124j26
resistor 120K 1/6W ± 5% CF 26mm
1 R233
110-16151j26
resistor 150Ω 1/6W ± 5% CF 26mm
1 R253
110-16153j26
resistor 15K 1/6W ± 5% CF 26mm
2 R107,234
110-16154j26
resistor 150K 1/6W ± 5% CF 26mm
1 R252
110-16182j26
resistor 1.8K 1/6W ± 5% CF 26mm
1 R145
110-16183j26
resistor 18K 1/6W ± 5% CF 26mm
1 R262
110-16203j26
resistor 20K 1/6W ± 5% CF 26mm
1 R309
110-16205j26
resistor 2M 1/6W ± 5% CF 26mm
1 R257
110-16221j26
resistor 220Ω 1/6W ± 5% CF 26mm
1 R144
110-16222j26
resistor 2.2K 1/6W ± 5% CF 26mm
1 R102
110-16223j26
resistor 22K 1/6W ± 5% CF 26mm
5 R238,247,255,256,316
110-16273j26
resistor 27K 1/6W ± 5% CF 26mm
2 R223,237
110-16333j26
resistor 33K 1/6W ± 5% CF 26mm
1 R310
110-16393j26
resistor 39K 1/6W ± 5% CF 26mm
1 R151
110-16472j26
resistor 4.7K 1/6W ± 5% CF 26mm
3 R200,207,58
110-16473j26
resistor 47K 1/6W ± 5% CF 26mm
7 R106,129,219,249,250,251,264
110-16474j26
resistor 470K 1/6W ± 5% CF 26mm
2 R127,312
110-16512j26
resistor 5.1K 1/6W ± 5% CF 26mm
2 R210,211
110-16513j26
resistor 51K 1/6W ± 5% CF 26mm
1 R224
110-16562j26
resistor 5.6K 1/6W ± 5% CF 26mm
1 R152
110-16621j26
resistor 620Ω 1/6W ± 5% CF 26mm
1
R160
110-16751j26
resistor 750Ω 1/6W ± 5% CF 26mm
1
R315
110-16755j26
resistor 7.5M 1/6W ± 5% CF 26mm
1
R313
110-16913j26
resistor 91K 1/6W ± 5% CF 26mm
4
R203,204,205,206
116-161002f26
metal film resistor 10K 1/6W ± 1% MF 26mm
2 R301,303
116-161102f26
metal film resistor 11.0Ω 1/6W ± 1% MF 26mm
1 R302
116-162200f26
metal film resistor 220Ω 1/6W ± 1% MF 26mm
1 R317
116-162202f26
metal film resistor 22.0K 1/6W ± 1% MF 26mm
1 R318
110-12472j52 resistor 4.7K 1/2W ± 5% CF 52mm 2 R201,202
110-20332jk2 resistor 3.3K 2W ± 5% CF 7.5mm 1 R134
113-50s68j00 cement resistor 0.068Ω 5W ± 5% 7.5mm 1 R147
115-h503a102 variable resistor RV16AE-20B2 -A54-104 LEVEL 1 VR201
116-201001jk3x metal film resistor 1.00K ± 5% 2W 7.5mm 1 R148
116-304700jk2x metal film resistor 470Ω ± 5% 3W 10mm 2 R501,502
Capacitors
129-a154j633
metallize capacitor 0.15U 63V ± 5% MSC
2 C221,222
130-2b221k503
disc capacitor 220P 50V ± 10%
12 C200,204,205,207,208,210,211,212,214,220,230,249
130-2b470k503
disc capacitor 47P 50V ± 10%
1 C229
130-2f104z503 disc capacitor 0.1U 50V +80/-20% 14 C17,117,122,144,232,242,244,245,246,252,254,256,320, 322
130-sl101k503
disc capacitor 100P 50V SL ± 10%
3 C302,303,306
132-103j503 mylar capacitor 0.01U 50V ± 5% 4 C223,224,305,317
132-103ja03
mylar capacitor 0.01uF 100V ± 5%
2 C103,104
132-104ja03
mylar capacitor 0.1uF 100V ± 5%
4 C123,218,503,504
132-223ja03
mylar capacitor 0.022uF 100V ± 5%
1 C215
132-273ja03
mylar capacitor 0.027uF 100V ± 5%
1 C143
132-473ja03
mylar capacitor 0.047uF 100V ± 5%
2 C216,217
135-3105m50
electrolytic 1U 50V ± 20%
1 C228
135-3106m50
electrolytic 10uF 50V ± 20%
12 C201.202.206.213.219.231.241.243.251.253.319.321
135-3107m10
electrolytic 100U 10V ± 20%
2 C114,115
