Part Number Description Qty Reference Designator
Input/Main PCBs
135-3107m16
electrolytic 100uF 16V ± 20%
1 C234
135-3107m35
electrolytic 100U 35V ± 20%
2 C507,508
135-3225m50
electrolytic 2.2U 50V ± 20%
1 C509
135-3226m16
electrolytic 22U 16V ± 20%
1 C304
135-3226m50
electrolytic 22U 50V ± 20%
3 C225,505,506
135-3227m16
electrolytic 220U 16V ± 20%
2 C118,233
135-3476m16
electrolytic 47U 16V ± 20%
1 C318
132-103kb00 mylar capacitor 0.01uF 200V ± 10% 1 C500
135-4478m63 electrolytic cap 4700uF 63V ± 20% 2 C501,502
Semiconductors
192-027c1815gr transistor 2SC1815GR NPN 9 Q108,109,113,201,206,207,208,301,302
192-027c2235y transistor 2SC2235Y NPN 1 Q111
192-028a1015gr transistor 2SA1015GR PNP 3 Q101,107,112
192-1672n5551 transistor 2N5551 NPN 2 Q114,115
192-1682n5401 transistor 2N5401 AI-PNP 350V 500mA TO-92 1 Q503
197-031n4148 diode 100mA 75V SIGNAL 1N4148 ROHM 20
D102,103,104,105,143,201,202,203,204,205,206,207,208,
211,212,214,215,216,302,302
199-15000335 zener diode 3.3V 1/2W 52mm 1 D213
199-15000625 zener diode 6.2V 1/2W 52mm 1 D101
199-15001605 zener diode 16V 1/2W 52mm 1 D502
190-06m4558d IC OPA 4558D DUAL OP-AMP 1 U203
190-16t1074cn IC TL074CN ST QUAD OP-AMP 3 U201,202,301
192-161tip31c transistor TIP31C SGS NPN 1 Q501
192-162tip32c transistor TIP32C SGS PNP 1 Q502
195-10204hgw LED 204HGW 1 D209
197-00kbu606g diode 6A 800V KBU606G 1 D501
197-141n4004 diode 1N4004 2 D110,504
Miscellaneous
109-1ttc802j0 thermister TTC-802(JS) NTC 1 TH1
120-1000003
inductor 10W AI YT-C3104-005 1CRHW 354708LTB 2 FB1,2
162-10060003
wire 60mm S412P
1 J104 TO W2
162-50129001 wire cable ass'y 120mm AWG28 WHT 1 W201
171-urwh124d relay RWH-SH-124D (1600ohm) 1 RL1
174-0rca108gv jack RCA-108GV JK203 1 JK201
174-0rcb202vg jack RCA JK RCB-202VD(G) A=WHIT/B=RED 1 JK202
174-20810360g jack spk JK BP 8PIN SH0810360G US1.35 1 JK203
175-1c07v01 wire connector 7PIN PITCH=2.5mm 1 M201
180-tms7210v
switch slide 6PIN MS7210V
1 SW201
Power Amp Class D Module part# 012-7500-00022 RECOMMENDED: REPLACE ENTIRE MODULE
Resistors
118-12061001j SMD resistor 1.00K 1206 5% 4 R2,11,29,30
118-12061002j SMD resistor 10.0K 1206 5% 3 R7,9,25
118-120610r0j SMD resistor 10.0Ω1206 5% 2 R22,23
118-12061201j SMD resistor 1.20K1206 5% 16 R31,32,33,34,35,36,37,38,39,40,41,42,43,44,45,46
118-12062002j SMD resistor 20.0K1206 5% 1 R26
118-12062201j SMD resistor 2.20K 1206 5% 3 R6,13,16
118-12062701j SMD resistor 2.70K 1206 5% 1 R10
118-12063000j SMD resistor 300.0Ω 1206 5% 1 R24
118-12063301j SMD resistor 3.30K 1206 5% 4 R14,15,27,28
118-12063902j SMD resistor 39.0K 1206 5% 1 R3
118-12064700j SMD resistor 470Ω 1206 5% 1 R8
118-12064701j SMD resistor 4.70K 1206 5% 3 R1,5,12
118-12064702j SMD resistor 47.0K 1206 5% 1 R17
118-12064704j SMD resistor 4.70M 1206 5% 1 R4
118-120647r0j SMD resistor 47.0Ω 1206 5% 2 R20,21
SUB300 (SCS300.7sys)
120v Electrical parts List cont'd
