JBL SUB300 - 230 V ELECTRICAL PARTS LIST

Part Number Description Qty Reference Designator
Module Class D DS-150
Capacitors
141-c0101k50 SMD capacitor 100pF 50V 10% 1206 NP0 1 C4
141-c0220k50 SMD capacitor 22pF 50V 10% 1206 SMT NP0 1 C5
141-c0561k50 SMD capacitor 560pF 50V 10% 1206 NP0 1 C6
141-c5104m50 SMD capacitor 1206 Y5V 0.1uF 50V ± 20% 8 C2,3,7,8,9,10,11,15
141-c7223k50 SMD capacitor 0.022uF 50V 10% 1206 X7R 1 C13
141-d7104ka0 SMD capacitor 0.1uF 100V 10% 1206 X7R 2 C12,14
141-d7104ka5 SMD capacitor 0.1uF 250V 10% 1210 X7R 4 C1,18,19,20
128-e106ma01
non-polar 10uF 100V 20%
2 C16,17
Semiconductors
190-16tl072dts SMD I.C TL072CDT SGS DUAL OP-AMP 1 IC1
192-09124126qs SMD transistor 2SC2412K-T146Q/R ROHM 3 Q1,4,5
192-09139066rs SMD transistor 2SC3906K-T146R ROHM 2 Q2,8
192-09210376qd SMD transistor 2SA1037K-T146Q/R ROHM 2 Q7,9
192-09215146rs SMD transistor 2SA1514K-T146R ROHM 2 Q3,6
197-03rls4148s SMD diode RLS4148-TE11 ROHM 6 D1,2,3,4,5,6
199-15000563s SMD zener diode 5.6V 5% PHILIPS BZX84-C5V6 2 Z1,2
199-15001203s SMD zener diode 12V 5% PHILIPS BZX84-C12 2 Z5,6
199-15001503s SMD zener diode 15V 5% PHILIPS BZX84-C15 2 Z3,4
192-232irf9640 transistor FET IRF9640 IR P-CH TO220 1 Q10
192-233irf640
transistor FET IRF640 IR P-CH TO220
1 Q11
Miscellaneous
122-14121m4191
inductor ferrite core LS-A6206-ST EFD-30
1L1
122-14350j4180
inductor 35uH ferrite core 25 milliohm
1L2
175-9f40hr2 wire connector 40PIN PITCH=2.54mm HR2*40
MISCELLANEOUS
130-2f104z503 disc capacitor 0.1U 50V +80/-20% TAP 1 C110
150-r4055900 power transformer I/P: 120V/60Hz TT0900008720 1 T501
152-u602015 line cord SVT FT-26FT 1
154-k31505t0 fuse 3.15A 250V 30mm UL/CSA/PSE 1 F501
155-63032i fuse holder HTB-32I 30mm UL/CSA 1 for 501
162-10082007 wire RED 18AWG 8mm#1015 1
162-a040d001 wire #1515 400mm 9911110-00 1
176-wjce1 wire connector pin CE-1 1
180-pbr12c11s switch PUSH BR12C11S 1 SW501
193-201815t2 insulator 1
302-AL-00020-0LC Alu. Panel 1
306-ABS-00004 Rear cover 1
311-ABS-00028 Plastic switch 1
317-000-00037 Terminal 1
323-AL-00056 Heat sink 1
333-EVA-00096 EVA (Gasket) 2
333-EVA-00097 EVA (Gasket) 2
333-EVA-00132 EVA (Gasket) 2
333-EVA-00133 EVA (Gasket) 2
333-EVA-00188 EVA (Gasket) 1
333-EVA-00219 EVA (Gasket) 1
333-EVA-00220 EVA (Gasket) 1
335-NYL-00002 Cable sheet 2
350-EM04012D024 Screw 4
351-AM03008A078 Screw 4
351-AM03008A079 Screw 2
352-AM03008D040 Screw 2
352-AM03008D041 Screw 2
352-AM03040D065 Screw 4
352-HM03012D086 Screw 1
362-FE-00013 PCB holder 2
SUB300 (SCS300.7sys)
120v Electrical parts List cont'd
15
