SUB300 230v Electrical parts List
Part Numbe
r
Descriptio
n
Qt
y
Reference Desi
g
nato
r
Input/Main PCBs
Resistors
110-14103j26 Resistor 10K 1/4W ± 5% CF 26mm TAP
3 R503,504,510
110-14222j26 Resistor 2.2K 1/4W ± 5% CF 26mm TAP
1
R511
110-14432j26 Resistor 4.3K 1/4W ± 5% CF 26mm TAP
1 R506
110-14472j26 Resistor 4.7K 1/4W ± 5% CF 26mm TAP
1 R505
110-16102j26
Resistor 1K 1/6W ± 5% CF 26mm TAP
5 R153,213,214,215,254
110-16103j26 Resistor 10K 1/6W ± 5% CF 26mm TAP
28
R128,130,149,150,209,212,216,217,220,221,222,225,226,
227,228,229,230,232,235,240,248,260,305,306,308,311,
314,319
110-16104j26
Resistor 100K 1/6W ± 5% CF 26mm TAP
6 R122,126,231,263,266,307
110-16105j26
Resistor 1M 1/6W ± 5% CF 26mm TAP
1 R259
110-16122j26
Resistor 1.2K 1/6W ± 5% CF 26mm TAP
1 R265
110-16124j26
Resistor 120K 1/6W ± 5% CF 26mm TAP
1 R233
110-16151j26
Resistor 150Ω 1/6W ± 5% CF 26mm TAP
1 R253
110-16153j26
Resistor 15K 1/6W ± 5% CF 26mm TAP
2 R107,234
110-16154j26
Resistor 150K 1/6W ± 5% CF 26mm TAP
1 R252
110-16182j26
Resistor 1.8K 1/6W ± 5% CF 26mm TAP
1 R145
110-16183j26
Resistor 18K 1/6W ± 5% CF 26mm TAP
1 R262
110-16203j26
Resistor 20K 1/6W ± 5% CF 26mm TAP
1 R309
110-16205j26
Resistor 2M 1/6W ± 5% CF 26mm TAP
1 R257
110-16221j26
Resistor 220Ω 1/6W ± 5% CF 26mm TAP
1 R144
110-16222j26
Resistor 2.2K 1/6W ± 5% CF 26mm TAP
1 R102
110-16223j26
Resistor 22K 1/6W ± 5% CF 26mm TAP
5 R238,247,255,256,316
110-16273j26
Resistor 27K 1/6W ± 5% CF 26mm TAP
2 R223,237
110-16333j26
Resistor 33K 1/6W ± 5% CF 26mm TAP
1 R310
110-16393j26
Resistor 39K 1/6W ± 5% CF 26mm TAP
1 R151
110-16472j26
Resistor 4.7K 1/6W ± 5% CF 26mm TAP
3 R200,207,258
110-16473j26
Resistor 47K 1/6W ± 5% CF 26mm TAP
7 R106,129,219,249,250,251,264
110-16474j26
Resistor 470K 1/6W ± 5% CF 26mm TAP
2 R127,312
110-16512j26
Resistor 5.1K 1/6W ± 5% CF 26mm TAP
2 R210,211
110-16513j26
Resistor 51K 1/6W ± 5% CF 26mm TAP
1 R224
110-16562j26
Resistor 5.6K 1/6W ± 5% CF 26mm TAP
1 R152
110-16621j26
Resistor 620Ω 1/6W ± 5% CF 26mm TAP
1
R160
110-16751j26
Resistor 750Ω 1/6W ± 5% CF 26mm TAP
1
R315
110-16755j26
Resistor 7.5M 1/6W ± 5% CF 26mm TAP
1
R313
110-16913j26
Resistor 91K 1/6W ± 5% CF 26mm TAP
4
R203,204,205,206
116-161002f26
metal film Resistor 10K 1/6W ± 1% MF 26mm TAP
2 R301,303
116-161102f26
metal film Resistor 11.0K 1/6W ± 1% MF 26mm TAP
1 R302
116-162200f26
metal film Resistor 220Ω 1/6W ± 1% MF 26mm TAP
1 R317
116-162202f26
metal film Resistor 22.0K 1/6W ± 1% MF 26mm TAP
1 R318
110-12472j26 Resistor 4.7K 1/2W ± 5% CF 52mm TAP
2 R201,202
110-20332jk3
Resistor 3.3K 2W ± 5% 7.5mm
1 R134
113-50s68j00 cement Resistor 0.068Ω 5W ± 5%
1 R147
115-h503a102 variable Resistor RV16AE-20B2 -A54-104(A50K)
1 VR201
116-201001jk3x metal film Resistor 1.00K 2W± 5% 7.5mm
1 R148
116-304700jk2x metal film Resistor 470Ω 3W± 5% 10mm
2 R501,502
Capacitors
129-a154j633
metallize capacitor 0.15U 63V ± 5% MSC TAP
2 C221,222
130-2b221k503
disc capacitor 220P 50V ± 10% TAP
12 C200,204,205,207,208,210,211,212,214,220,230,249
130-2b470k503
disc capacitor 47P 50V ± 10% TAP
1 C229
130-3f104z503 disc capacitor 0.1U 50V +80/-20% TAP
14
C107,117,122,144,232,242,244,245,246,252,254,256,320,
322
130-sl101k503
disc capacitor 100P 50V SL ± 10% TAP
3 C302,303,306
132-103j503 Mylar capacitor 0.01UF 50V ± 5% TAP
4 C223,224,305,317
132-104ja03
Mylar capacitor 0.1uF 100V ± 5% TAP
4 C123,218,503,504
132-223ja03
Mylar capacitor 0.022uF 100V ± 5% TAP
1 C215
SUB300 (SCS300.7sys)
