JBL SUB300 - 230 V Electrical Parts List

Part Numbe
r
Descriptio
n
Qt
y
Reference Desi
g
nato
r
Input/Main PCBs
132-273ja03
Mylar capacitor 0.027uF 100V ± 5% TAP
1 C143
132-473ja03
Mylar capacitor 0.047uF 100V ± 5% TAP
2 C216,217
135-3105m50
electrolytic 1U 50V ± 20% TAP
1 C228
135-3106m50
electrolytic 10uF 50V ± 20% TAP
12 C201.202.206.213.219.231.241.243.251.253.319.321
135-3107m10
electrolytic 100U 10V ± 20% TAP
2 C114,115
135-3107m16
electrolytic 100uF 16V ± 20% TAP
1 C234
135-3107m35
electrolytic 100U 35V ± 20% TAP
2 C507,508
135-3225m50
electrolytic 2.2U 50V ± 20% TAP
1 C509
135-3226m16
electrolytic 22U 16V ± 20% TAP
1 C304
135-3226m50
electrolytic 22U 50V ± 20% TAP
3 C225,505,506
135-3227m16
electrolytic 220U 16V ± 20% TAP
2 C118,233
135-3476m16
electrolytic 47U 16V ± 20% TAP
1 C318
129-a105ja04
metallize capacitor 1U 100V
2 C103,104
132-103kb00 Mylar capacitor 0.01uF 200V ± 10% TAP
1 C500
135-4478m63 electrolytic cap 4700uF 63V ± 20%
2 C501,502
Semiconductors
192-027c1815gr transistor 2SC1815GR NPN
9 Q108,109,113,201,206,207,208,301,302
192-027c2235y transistor 2SC2235Y NPN
1 Q111
192-028a1015gr transistor 2SA1015GR PNP
3 Q101,107,112
192-1572n5551 transistor 2N5551 NPN
2 Q114,115
192-1582n5401 transistor 2N5401 AI-PNP 350V 500mA TO-92
1 Q503
197-031n4148 diode 100mA 75V SIGNAL 1N4148 ROHM TAP
20
D102,103,104,105,143,201,202,203,204,205,206,207,208,
211,212,214,215,216,301,302
199-15000335 zener diode 3.3V 1/2W 52mm TAP
1 D213
199-15000625 zener diode 6.2V 1/2W 52mm TAP
1 D101
199-15001605 zener diode 16V 1/2W 52mm TAP
1 D502
190-06m4558d IC OPA 4558D DUAL OP-AMP
1 U203
190-16t1074cn IC TL074CN ST QUAD OP-AMP
3 U201,202,301
192-161tip31c transistor TIP31C SGS NPN
1 Q501
192-162tip32c transistor TIP32C SGS PNP
1 Q502
195-10204hgw LED 204HGW
1 D209
197-00kbu606g diode 6A 800V KBU606G
1 D501
197-141n4004 diode 1N4004
2 D110,504
Miscellaneous
109-1ttc802j0
thermister TTC-802(JS) NTC
1 TH1
162-10060003
wire 60mm S412P
1 J104
162-50129001 wire cable ass'y 120mm AWG28 WHT
1 W201
171-urwh124d relay RWH-SH-124D (1600ohm)
1 RL1
174-0rca108gv jack RCA-108GV JK203
1 JK201
174-0rcb202ag jack RCA JKCA-209
1 JK202
174-20810360gx jack spk JK BP 8PIN SH0810360GX
1 JK203
175-1c07v01 wire connector 7PIN PITCH=2.5mm
1 M201
175-1d02v01 wire connector 2PIN PITCH=3.96mm
1 M100
175-1d03v01 wire connector 3PIN PITCH=3.96mm JST-VH
1 M500
180-tms7210v
switch slide 6PIN MS7210V
1 SW201
120-1000003 inductor 10W AI YT-C3104-005 1CRHW 354708LTB
2 FB1,2
Module Class D DS-150
Resistors
118-12061001j SMD Resistor 1.00K 1206 5%
4 R2,11,29,30
118-12061002j SMD Resistor 10.0K 1206 5%
3 R7,9,25
118-120610r0j SMD Resistor 10.0Ω1206 5%
2 R22,23
118-12061201j SMD Resistor 1.20K1206 5%
16 R31,32,33,34,35,36,37,38,39,40,41,42,43,44,45,46
118-12062002j SMD Resistor 20.0K1206 5%
1 R26
118-12062201j SMD Resistor 2.20K 1206 5%
3 R6,13,16
SUB300 (SCS300.7sys)
230v Electrical parts List cont'd
17
