JBL SUB300 - INTEGRATED CIRCUIT DIAGRAMS

Part Numbe
r
Descriptio
n
Qt
y
Reference Desi
g
nato
r
Module Class D DS-150
118-12062701j SMD Resistor 2.70K 1206 5% 1 R10
118-12063000j SMD Resistor 300.0Ω 1206 5%
1 R24
118-12063301j SMD Resistor 3.30K 1206 5%
4 R14,15,27,28
118-12063902j SMD Resistor 39.0K 1206 5%
1 R3
118-12064700j SMD Resistor 470Ω 1206 5%
1 R8
118-12064701j SMD Resistor 4.70K 1206 5%
3 R1,5,12
118-12064702j SMD Resistor 47.0K 1206 5%
1 R17
118-12064704j SMD Resistor 4.70M 1206 5%
1 R4
118-120647r0j SMD Resistor 47.0Ω 1206 5%
2 R20,21
Capacitors
141-c0101k50 SMD capacitor 100pF 50V 10% 1206 NP0
1 C4
141-c0220k50 SMD capacitor 22pF 50V 10% 1206 SMT NP0
1 C5
141-c0561k50 SMD capacitor 560pF 50V 10% 1206 NP0
1 C6
141-c5104m50 SMD capacitor 1206 Y5V 0.1uF 50V ± 20%
8 C2,3,7,8,9,10,11,15
141-c7223k50 SMD capacitor 0.022uF 50V 10% 1206 X7R
1 C13
141-d7104ka0 SMD capacitor 0.1uF 100V 10% 1210 X7R
2 C12,14
141-d7104ka5 SMD capacitor 0.1uF 250V 10% 1210 X7R
4 C1,18,19,20
128-e106ma01
non-polar 10uF 100V 20%
2 C16,17
Semiconductors
190-16tl072dts SMD I.C TL072CDT SGS DUAL OP-AMP
1 IC1
192-09124126qs SMD transistor 2SC2412K-T146Q/R ROHM
3 Q1,4,5
192-09139066rs SMD transistor 2SC3906K-T146R ROHM
2 Q2,8
192-09210376qd SMD transistor 2SA1037K-T146Q/R ROHM
2 Q7,9
192-09215146rs SMD transistor 2SA1514K-T146R ROHM
2 Q3,6
197-03rls4148s SMD diode RLS4148-TE11 ROHM
6 D1,2,3,4,5,6
199-15000563s SMD zener diode 5.6V 5% PHILIPS BZX84-C5V6
2 Z1,2
199-15001203s SMD zener diode 12V 5% PHILIPS BZX84-C12
2 Z5,6
199-15001503s SMD zener diode 15V 5% PHILIPS BZX84-C15
2 Z3,4
192-232irf9640 transistor FET IRF9640 IR P-CH TO220
1 Q10
192-233f640
transistor FET IRF640 IR P-CH TO220
1 Q11
Miscellaneous
175-9f40hr2 wire connector 40PIN PITCH=2.54mm HR2*40
0.2
122-14121m4191
inductor ferrite core LS-A6206-ST EFD-30
1 L1
122-14350j4180
inductor 35uH ferrite core 25 milliohm
1 L2
FILTER PCB ASS'Y
122-14103m4200
inductor RT251510*103N 10mH
2 L501
132-104kb70 m
y
lar capacitor 0.1uF 275V ± 10% VD
E
1 C499
132-224kb70 m
y
lar capacitor 0.22uF 275V ± 10% 1 C498
MISCELLANEOUS
130-3f104z503 disc capacitor 0.1U 50V +80/-20% TA
P
1 C110
150-r4055901 230v power transforme
r
1 T501
152-v60202603 line cord 6FT SPO21A H03VVH2-
F
1
154-k16006t0 fuse 1.6A 250V VBS UTE-TYPE UL/BSI/VDE 1 F501
155-620001 fuse holder HTB-32M UL/CSA/VD
E
1 for F501
162-10121002 wire UL1617 120mm BRN 20
#
1
162-10126001 wire UL1617 120mm BLU 20
#
1
162-10152001 wire UL1617 AGW22 150mm RED 6:
6
1
162-a040d001 wire #1015 400mm 991110-0
0
1 M100
180-prf1003d switch ROCK RF-1003-BB4-O POWER 1
193-201815t2 insulator 1
SUB300 (SCS300.7sys)
230v Electrical parts List cont'd
18
