Specifications
ANCA Motion D-000168 Rev 02 23
5
Mechanical 5.3
NOTE: The motor housing tolerances must be considered when designing a system for fluid cooling.
9.759.75
Figure 5-5 - Mechanical Dimensions
Forcer 5.3.1
TLMS-18P
TLMS-27P
TLMS-36P
TLMS-36H
Length [Lm] (mm)
210.5
300.5
390.5
390.5
Weight (kg)
6.5
8.8
11.4
11.4
Shaft 5.3.2
Shaft length [Ls] (mm)
Stroke [s] (mm)
TLMS-18P
TLMS-27P
TLMS-36(P,H)
360
30
N/A
N/A
390
60
420
90
450
120
30
480
150
60
510
180
90
540
210
120
30
570
240
150
60
600
270
180
90
630
300
210
120
660
330
240
150
690
360
270
180
720
390
300
210
750
420
330
240
780
450
360
270
810
480
390
300
