33 - 2
No. Description Qty.
1 Valve Housing 1
2 Spool - Travel Right 1
3 Spool - Bucket 1
4 Spool - Boom 1 1
5 Spool - Arm2 1
6 Spool - Swing 1
7 Spool - Arm 1 1
8 Spool - Boom 2 1
9 Spool - Reserve 1
10 Spool - Travel Left 1
11 O-ring 18
12
13 Cap 1
14 Cap 1
15 Spring Seat 18
16 Spring 9
17 Spool End 9
18 Shuttle (A) 1
19 Spring 1
20 Plug 1
21 Plug Assembly (with mesh filter) 1
22 Poppet 1
23 Spring 2
24 Sleeve 1
25 Sleeve (A) 1
26 Poppet 2
27 Spring 2
28 Poppet 2
29 Spring 2
30 O-ring 4
31 Plug 3
32 O-ring 8
33 Poppet 1
34 Plug 1
35 Poppet (Load Check) 8
36 Spring (Load Check) 8
37 Plug 8
38 Sleeve 1
39 Plug 1
40 Socket Head Bolt 17
41 Socket Head Bolt 2
42 Socket Head Bolt 11
43 Plug 14
44 Plug Assembly 3
45 Plug Assembly 3
46 Plug Assembly 5
47 Plug Assembly 4
48 Relief Valve Kit 1
49 Relief Valve Kit 5
50 Shut-Off Valve Assembly 2
51 Anti-Drift Valve assembly 2
52 Relief Valve kit 1
53 Poppet 2
54 Spring 2
55 Spacer 2
56 O-ring 5
57 Back-Up Ring 4
58 Poppet 15
59 Spring 15
60 Plug 15
61 Name plate 1
62 Drive Screw 4
Section E Hydraulics
9803/6020
Section E
33 - 2
Issue 1
Control Valve
