3 - 3
Section C Electrics
9803/6020
Section C
3 - 3
Issue 1
Cab Layout
Right Console (cont’d)
5 Work Lamp Switch
This switch turns the work lamp ON and OFF.
6 (Work) Mode Selection Switch
This switch selects the mode suitable for the work to
be done.
Note: When the engine is started, the standard mode is
automatically indicated and selected.
S: STANDARD MODE
For standard digging and loading work.
L: LIGHT MODE
For accurate work where speed is not paramount.
7 Wiper Switch
The switch that controls the windshield wiper.
Using the wipers when the windshield is dry or when
it is soiled with dirt or with snow can cause damage
to the blades. Please use caution in such cases.
8 Washer Switch
Washer fluid is sprayed and the wipers move as long
as the switch is pressed.
Note: Do not press when there is no washer liquid or the
motor will seize. The washer liquid tank is located in the
tool box in front of the fuel tank.
Switch Lamp Wiper Function
OFF Stop
1 ON Works intermittently
2 ON Works
continuously
Switch Lamp Work Lamp
OFF All Off
1 On Right hand Cab
Working light Only
2 On Right hand Cab
& Boom Light on
To Next Page
