JCM VEGA Series User Manual

P/N 960-100189RA_Rev. A {EDP #148850} © 2009, Japan CashMachine Co., Limited
1-11
General Information VEGA™ Series BankNote Validator Section 1
E NTIRE U NIT O UTSIDE D IMENSIONS (T YPE SD/SU B ACK A CCESS )
Figure 1-12 illustrates the entire VEGA SD/SU Back Access Unit outside dimensions.
VEGA C ASH B OX O UTSIDE D IMENSIONS (S TANDARD C ASH B OX )
Figure 1-13 illustrates the VEGA Standard Cash Box’s outside dimensions.
NOTE: All Dimension are in Millimeters
NOTE: Only the Standard Cash Box is available in this style.
Fi 1 12 VEGA B k t V lid t U it O t id Di i (T SD/SU R A )
NOTE: All Dimension are in Millimeters
Figure 1-13 VEGA Cash Box Outside Dimensions (Standard Cash Box)
