Ethernet cable connection diagram
The following diagram is for reference only. The appearance and model of the
camera you purchased may be different, but it won't affect the setup.
If you choose a wireless connection, please skip the "Ethernet cable Connec-
tion" part and refer to the "Wireless Connection" part.
For Ethernet cable connection:
1.Plug in the power supply for your camera.
2.Connect your router and camera with an Ethernet cable.
Reset button
Antenna
Power supply port
Surveillance Camera
LAN port
Mobile phone
If the power cable of your camera is too long,
it may damage the conductive function.
Therefore, please make sure that the power
cable of your camera is not too long.
To Next Page
