Jensen VM9414 - Page 25

20
VM9414
Treble
Freq
8kHz Adjust Treble boost/cut frequency. Range of adjustment is +/
- 12 dB.
10kHz
12.5kHz
15khz
Subfilter 80Hz Select a crossover frequency to set a cut-off frequency for
the subwoofer's LPF (low-pass filter).
100Hz
120Hz
140Hz
160Hz
Bass Q-
Factor
Wide 1 Adjust the "Q" or width of the bass control of the Bass Freq
selected.
Wide 2
Narrow 1
Narrow 2
iPod Gain -7 to 7 Increase or reduce the relative volume (Gain).
Auxin
Gain
-7 to 7 Increase or reduce the relative volume (Gain).
SAT Gain -7 to 7 Increase or reduce the relative volume (Gain).
DISC/
USB/SD
Gain
-7 to 7 Increase or reduce the relative volume (Gain).
Tuner
Gain
-7 to 7 Increase or reduce the relative volume (Gain).
Setting Options Function
