Equalizer Controls
Equalizer (EQ): Adjustments can be made after entering one
of the audio/video sources (Disc, Radio, USB, AV IN 1, or AV
IN 2) Touch the Equalizer (EQ) icon to view the Equalizer Control Screen
to make adjustments to the audio Balance and Fader levels. Touch the
return icon to return to the current source.
Playing a Disc
To begin playback of an Audio/Video Disc:
1. Press the front panel Power/Volume/Mute control knob to turn the unit ON.
2. Insert a disc with the label side facing UP and playback will begin
automatically.
Parking Brake Inhibit
When the pink “Parking” wire is connected to the vehicle Parking Brake circuit,
the front TFT monitor will display video when the Parking Brake is engaged.
SYSTEM SETTINGS
1. Press the Menu button to display the Main SRC Menu.
2. Touch the Settings icon [ ] and the Settings Menu is displayed.
To Next Page
