General
Auxiliary (Audio) Input Impedance: 10k-Ohm
Power Supply: 11 to 16VDC, Negative Ground
Power Antenna / Amp Remote (Blue): 500mA Max (Current Limited Protection)
Operating Temperature: 0C ~ 65C / 32F ~ 149F
Fuse: 15-Amp, ATO Type
Chassis Dimensions: 7” x 7” x 4” (178mm x 178mm x 100mm)
CEA Power Ratings
Power Output: 13 Watts RMS x 4 Channels Into 4-
Ohms @ < 1% THD+N
Signal to Noise Ratio: 70dBA Below Reference
(Reference: 1 Watt, 4-Ohms)
Frequency Response: 20Hz - 20kHz, -3dB. (Aux
Input Used as Reference Input)
Reference Supply Voltage: 14.4VDC
*Specifications Subject to Change Without Notice.
