Section 7 : Specifi cations
5376000277 7-1
SECTION 7 - SPECIFICATIONS
7.1 PRODUCT SPECIFICATIONS
MPL-40
OPERATING SPECIFICATIONS AND PERFORMANCE DATA
DO NOT EXCEED THE FOLLOWING RATINGS:
BOOM RATING: (SAE J2512 Rating)
Extended (Boom elevated at 30° Angle
2)
.........................................6,000 lbs.
Retracted .............................................................. .........................16,000 lbs.
WINCH RATING: (Standard Worm Gear) ..................................................8,000 lbs.
2
WIRE ROPE:
Working Limit Each Line ................................................................. 4,300 lbs.
Construction ................................................................6 x 25 EIPS RRL IWRC
Diameter ............................................................................................ 3/8 inch
Standard Length ................................................................................110 Feet
UNDERLIFT RATING: (Reference underlift serial number tag)
Full Extended ..................................................................................4,000 lbs.
1
Tow Rating ......................................................................................7,500 lbs.
1
5th WHEEL ATTACHMENT (OPTIONAL WITH HYDRAULIC GRIDS ONLY):
Lifting Capacity ............................................................................... 4,000 lbs.
Towing Capacity ................................................................. .. .......... 7,500 lbs.
GOOSENECK ATTACHMENT (OPTIONAL WITH HYDRAULIC GRIDS ONLY):
Lifting Capacity ............................................................................... 4,000 lbs.
Towing Capacity ................................................................. .. ..........7,500 lbs.
1
TOWBALL HITCH:
2 in. Reese Receiver (OPTIONAL WITH HYDRAULIC GRIDS ONLY):
Lifting Capacity ............................................................................... 1,000 lbs.
Towing Capacity ................................................................. .. .........10,000 lbs.
GROSS TRAILER WEIGHT ........................................3,000 Maximum Vertical Load
1
SAE J2512: Surface Vehicle Recommended Practices - Towing Equipment
Ratings and Practices
2
SAE J706: Surface Vehicle Recommended Practices - Rating of Winches
