Section 4: Operation
5376000277 4-19
4.5 TOWBALL HITCH ATTACHMENT
The MPL-40 is supplied with a Towball Hitch attachment that will allow you
to recover and tow trailers requiring a tow ball hookup.
1. Remove the towball hitch
attachment from the toolbox.
2. Use the bottom set of holes,
install the towball hitch to the
bottom of the underlift boom
using the hitch pins.
3. Secure the hitch pins with the
lynch pins.
4. Install the desired towball to the
towball hitch.
5. Position the ball coupler over
the ball and lock into place.
Make sure that the ball and
coupler are of the same
matched size.
