Section 4 : Operation
4-4 5376000277
8. Next, lower the underlift using
the underlift down function
on the hand controller. The
underlift level stop assist
system will stop the underlift
travel at a preset position about
1-1/2” to 2” from the ground.
9. Extend the underlift under the
vehicle being sure that all under
carriage parts are cleared and
that the front portion of the
grid is in contact with both
tires. Lower the grid fully to the
ground. There is no reason for
the operator to get under the
vehicle.
10. Visually inspect the tire to grid
contact before proceeding.
To override either stop
position, simply release
the control function and
reactivate the same control
function again to achieve
further travel of the underlift.
