37
Wiring Diagram
200MFD 250 VAC
200MFD 250 VAC
WHITE
BLACK
BLACK
WHITE
GREEN
GREEN
30MFD 350 VAC
ELECTRICAL SCHEMATIC - 115V
RED
YELLOW
BLACK
WHITE
BLACK
WHITE
GREEN
GREEN
ELECTRICAL SCHEMATIC - 230V
GROUND
BLACK
WHITE
GREEN
BLACK
WHITE
GREEN
WHITE
BLACK
WHITE
RED
BLACK
YELLOW
30MFD 350 VAC

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Jet JWTS-10 and is the answer not in the manual?

Jet JWTS-10 Specifications

General IconGeneral
Blade Diameter10 inch
Table Size20 x 27 inch
Max Rip Capacity30 inch
Arbor Size5/8 inch
Max Rip to Left of Blade12 in
