consumption is higher when the values for the output period are
lower. This can lead to vibration in some servos if the values are set
too low.
• Erase data – by pushing the arrows R and L (right and left)
together, the minimum and maximum are reset, see "MIN / MAX -
Minimum / Maximum".
• Shutdown Voltage - input voltage level at which the Central Box
automatically turns off. If Central Box evaluates the input voltage is
lower than the stop level for more than 60 seconds, it automatically
turns off.
4.4 Out Pin Set
*CENTRAL BOX*: Out Pin Set – pushing the D button (down arrow)
moves you to basic settings of particular outputs of the Central Box.
• Set Output pin -selection of the slot that will be used for the
following settings. In this menu the output deflection of the
selected output is displayed as a percentage. Y1 is the Central Box
output labeled 1, Y2 is the Central Box labeled 2, etc.
• Function – setting of alternative functions of the outputs. This
function is available for outputs:
Central Box 200
• Y14 and Y15: Servo Output function or Telemetry Input.
• EXT1: Telemetry Input function or JETIBOX
Central Box 100:
• EXT1: Telemetry Input function or JETIBOX
• SetInChannel – assigns the input channel (marked as Chx) to a
specific output (marked as Yx)
• Reverse – reverses the output direction
• Signal Fault - setting behavior of the receiver in case of signal loss
• hold - repeats the last valid deflection command before
signal loss
• out off – does not generate any signal for servo in case of
signal loss
• FailSafe – transition to preset deflection of individual outputs
17 EN
